* Support AHD/TVI/CVI/CVBS/IP HD Video Input
* Support 4CH 1080N real-time Encode
* Support Coaxial- Cable Transmit Control Signal
* Support Cloud Service Function
* Support ONVIF Standard Protocol
* Support VGA/HDMI video output at the same time
* Support SDK private protocol integration
* Support Mobile App “ OK view”
* Support multiple interfaces selection and Boot LOGO update
5-in-1 2MP 4 Channel DVR
₦26,000.00
Technical Specifications
Model – D7104D-M
System
CPU – Embedded Processor Hi3521A
Screen
Preview – 1/4 channel Display
Video
Video Compression – H.264
Video Encode – 4*1080N@25fps
Video Decode – 4*1080N@25fps
ONVIF – Support
Input Mode – Analog : 4*1080N； Mix:2*1080N（Analog）+2*1080P（IP）;
Network: 4*1080P
Cloud – P2P
Audio
Audio Compression – G.711A
Talk-Back – Support
Record Mode – Manual/Alarm input/Motion Detection/Time
Record & PlayBack
Local Playback – 4 channels 1080P@25fps
Record Inquiry – Time/Date/Event/Channel
Storage & Backup
Storage – Hard disk/Network
Backup – Network/USB/SATA
Interface
Video Input – 4CH BNC
Video Output – VGA/HDMI
Audio I/O – None
Alarm I/O – None
Network – RJ45 10M/100M Ethernet Interface
PTZ – None
USB – 2 USB 2.0
Hard Disk – 1 SATA interface（each HDD maximum support 6TB）
Wireless – 3G、WIFI(Through USB interface expand)
General
Power Supply – 12VDC/2A
Power Consumption – Less 15W(without HDD)
Working Temperature – -10°C ~60°C
Working Humidity – 10% ~ 90% Humidity
