* Support AHD/TVI/CVI/CVBS/IP HD Video Input
* Support 4CH 5.0MP non real-time encode
* Support Coaxial- Cable Transmit Control Signal
* Support Cloud Service Function
* Support ONVIF Standard Protocol
* Support VGA/HDMI video output at the same time
* Support SDK private protocol integration
* Support Mobile App “ OKview”
* Support multiple interfaces selection and Boot LOGO update
5-in-1 4MP 4 Channel DVR
₦30,000.00
Technical Specifications
Model: D6104TH-GL
System
CPU – Embedded Processor Hi3521A
Screen
Preview – 1/4 channel Display
Video
Video Compression – H.264
Video Encode – 4*5MP@10fps
Video Decode – 4*5MP@10fps
ONVIF – Support
Input Mode – Analog: 4*4M@15fps / 4*3.0M@25fps /4*5.0M@10fps；
Mix： 4*1080P@25fps（Analog）+4*1080P@25fps（IP）
2*4.0M@25fps（Analog）+2*4.0M@25fps（IP）
Network: 8*1080P@25fps /4*3MP@25fps / 4*5MP@25fps
Cloud – P2P
Audio
Audio Compression – G.711A
Talk-Back – Support
Record Mode – Manual/Alarm input/Motion Detection/Time
Record & PlayBack
Local Playback – 4 channels 5.0MP@10fps
Record Inquiry – Time/Date/Event/Channel
Storage & Backup
Storage – Hard disk/Network
Backup – Network/USB/SATA
Interface
Video Input – 4CH BNC
Video Output – VGA/HDMI/CVBS
Audio I/O – 4CH/1CH
Alarm I/O – None
Network – RJ45 10M/100M Ethernet Interface
PTZ – PTZ RS485,support multiple PTZ protocols
USB – 2 USB 2.0
Hard Disk – 1 SATA interface（each HDD maximum support 6TB）
Wireless – 3G、WIFI(Through USB interface expand)
General
Power Supply –
12VDC/2A
Power Consumption – Less 15W(without HDD)
Working Temperature – -10°C ~60°C
Working Humidity – 10% ~ 90% Humidity
