Technical Specifications

Model – SN329JZ-4-S6
Camera
Sensor – 1/2.8″ 2.0MP Progressive Scan CMOS
Min. Illumination – 0.001Lux @(F1.2,AGC ON),0Lux with IR ON
Shutter – Auto /Manual, 1/25~1/100000
Lens Type – 2.8-12MM(3.6MM Optional)
IR LEDS – 4pcs Array LEDs, IR distance 40 meters
Video Compression – H.264
Bit Rate – 128Kbps~8Mbps
Max .Resolution – Main Stream: 1920×1080(25/30fps), Sub Stream: 720×576(25/30fps)
WDR – Digital WDR
Day&Night – Auto/Black&White/Color
Noise Reduction – Auto/manual
Exposure Mode – Auto/manual
Flip – Horizontal/Vertical
Audio Compression – G.711

Network
Protocols – TCP/IP,HTTP,FTP,DHCP,DNS,DDNS,RTP,RTSP, RTCP,PPPOE,NTP,SMTP
Interface Protocols – ONVIF /Private CGI
Cloud – P2P
Network – RJ45 ( 10M/100M Ethernet)

General
Audio input/output – Optional
Alarm input/output – Optional
Micro SD Slot – /
Waterproof – IP66
Working Temperature – -10℃~50℃
Working Humidity – 10%~90%
Power Consumption – 610 mA
Power Supply – DC12V±10% Built-in POE Optional
