• Slim and elegant design
• Vandal resistant metal housing, IP65
• Card read range: 0.8 to 3.1 in. (20 to 80 mm)
• BioNANO algorithm ensures fast verification under 1 second
• LED indicators and buzzer for visual and audio feedback
• Multiple verification modes guarantee flexibility and safety
• Multiple communication modes such as TCP/IP, Wiegand 26/34, easy for installation and integration
• Tamper alarm output
Anviz Intelligent Security – Outdoor Fingerprint & Card Reader/Controller ACFP006
Outdoor Fingerprint & Card Reader/Controller by ANVIZ is a compact access control device that is designed to fit most door frames. A metal casing, with IP65 water-proof design, makes it suitable for indoor or outdoor applications. M5 supports 125kHz proximity cards and fingerprint identification.It has both Wiegand and TCP/IP protocol interfaces and can be combined with SC011 (Power supply controller) to be a standalone access control device, or integrated with SAC844 (or professional distributed access controller from a third-party) to enable large-scale networks.
Technical Specifications
ltem – Description
Model – M5
Fingerprint Sensor – 500 dpi Optical Sensor
RFID Card Reader – EM(125KHz)
User Capacity – 2000
Fingerprint Capacity – 2000
Card Capacity – 2000
Log Capacity – 100,000
Verification Speed – < 1 Second(1:N)
Card Read Range - 0.8 to 3.1 in. (20 to 80 mm)
Identification Mode - Fingerprint/Card
Network Port - TCP/IP
Wiegand Protocol - Support Wiegand 26
Voice and Interface - Multicolor LEDs and Buzzer
Operating Voltage - DC 12V
Work Current - 150mA
Operating Temperature - -20°C to 60°C
Size(WxHxD) - 19.7 x 48.8 x 13.6 in. (50 x 124 x 34.5 mm)
Accessory - SC011(Controller)
Certificate - FCC, CE, ROHS
