Anviz Fingerprint & RFID Standalone Access Control ACFP009


Fingerprint & RFID access control system. It incorporate color LCD, keypad, optical fingerprint sensor, card reader and access control components.

SKU: ACFP009 Category: Tag:

• 3″ widescreen High Definition TFT display
• User friendly graphic interface
• New generation fully sealed, waterproof and dustproof AFOSfingerprint sensor
• BioNANO V10 core fingerprint algorithm of high speed and stability
• Support multiple display and software language, Suitable for local market.
• USB Plug & Play connection
• RS232/RS485, Mini USB Slave and TCP/IP for network connection
• Standard RFID, optional Mifare reader
• Clear voice prompts along with all operations
• 12-digit user ID and user name display
• 16 different customizable time and attendance status
• Auto time and attendance status switch
• 6-digit work code to calculate different job cost
• Public and private short message display
• Auto daylight saving
• Direct lock control to open door, door open sensor.
• Support Wiegand 26 Input and Output, Support Anviz Wiegand Output
• Optional SC011/SC844 or any other standard access controller for separate type secure access control system
• Time zone and group access control, realtime data transfer monitor
• Standard 3000 fingerprints and 50000 records

Technical Specifications

Model – C5
Algorithm BioNANO V10
Sensor – Anviz Optical Fingerprint Sensor
Scan – Area 22mm*18mm
LCD – 3″ Widescreen High Definition TFT Display
Identification Time – <0.5 Sec FRR - 0.001% FAR - 0.00001% Fingerprint Capacity - 3000 Log Capacity - 50000 Card Reader Module - 125KHZ EM RFID, Optional 13.56MHZ Mifare Identification Mode - FP, Card, ID+FP, ID+PW, PW+Card, FP+Card Voice Prompt - Support Multiple Languages Display and Voice Prompt Self-defined Status - 16 Work Code - 6-digit Work Code Short Message - Supports up to 50 public or private message simultaneously displayed Scheduled Bell - Yes Daylight Saving - Manual Mode, Automatic Mode Relay - 1 Relay Access Groups & Time Schedules - 16 Groups, 32 Time Zones Door Sensor - Yes Humidity - 20% ~ 80% RH Web Server - Yes Communication Interface - TCP/IP, USB host, USB, RS232, RS485 Wiegand - Support Wiegand 26 Input and Output, Support Anviz Wiegand Output Operating Voltage - DC12V, 1A Size - 168(w)*130(h)*37(d)mm Temperature - -20℃~60℃


Product Video
